Hospital Sturdy Black ORFIT Type Head-shoulder Baseplate

1. Carbon Fiber material;
2. ORFIT TYPE
3. Application: choose masks with 3, 4 or 5 points to meet the specific needs of the treatment.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Belly-Pelvis Baseplate

Product Overview

The ORFIT Type Head-Shoulder Baseplate is a carbon fiber positioning device designed for precise immobilization in radiation therapy. With a sturdy structure and >98% X-ray transmittance, it ensures both treatment accuracy and patient safety.

Why It Matters

Stable Immobilization: Reduces patient movement for consistent radiation targeting.
High Precision: Carbon fiber design offers minimal imaging interference (<0.2% error under 6MV X-ray).
Customizable Fit: Compatible with 3-, 4-, or 5-point thermoplastic masks to meet different treatment needs.
Lightweight Yet Strong: Only 1.5kg but supports up to 100kg patient load.

Technical Specifications

Registered Name: Positioning and Fixation for Radiation Therapy
Product ID: YC-KIII
Model: YC-DF114EU
Material: Carbon Fiber
X-ray Transmittance: >98%
Size: 540 × 555 × 12mm
Weight: 1.5kg
Max Load: 100kg

Clinical Application

Mount securely onto CT, simulator, or accelerator treatment beds via lock bar.
Thermoplastic mask clamps can be inserted into slots and fixed by blocks.
Compatible with ORFIT type accessories, ensuring versatile use for head and shoulder fixation in radiotherapy.

Maintenance & Handling

Storage: Keep in a clean, ventilated, and dry area. Avoid toxic or harmful substances.
Positioning: Store horizontally when not in use.
Cleaning: Wipe with alcohol or mild detergent.
Disposal: Non-toxic carbon fiber, can be disposed of as general waste.
